Item

Rating

Note

3.1    Capacity

Typical

12Ah

Discharge:0.2CmA

Minimum

11.5Ah

3.2    Nominal Voltage

Average  11.1V

3.3    AC Impedance Resistance

≤200mΩ

3.4    Discharge Cut-off Voltage

9.0V

3.5    Charge Current

2.4A

Standard Charge

3.6    Charge Voltage

12.6V

3.7    Max. Charge Voltage

12.69V

3.8    Charge Time

Approx 6.0h

Charge: 0.2CmA

3.9    Max. Charge Current

12A

1.0CmA

3.10   Max. Discharge Current

24A

2.0CmA

3.11   Weight

Approx 900g

3.12  Operating

Temperature

Charge

0~+45°C

Discharge

-20~+60°C

3.13  Storage

      Temperature

less than 1 month

-5~+35°C

Recommended storage

temperature: 20°C,at the

shipment state

less than 3 months

-5~+35°C
