Researchers develop viable sodium battery
June 1, 2020
Washington State University
Researchers have created a sodium-ion battery that holds as much energy and works as well as some commercial lithium-ion battery chemistries, making for a potentially viable battery technology out of abundant and cheap materials. The team reports one of the best results to date for a sodium-ion battery.
Washington State University (WSU) and Pacific Northwest National Laboratory (PNNL) researchers have created a sodium-ion battery that holds as much energy and works as well as some commercial lithium-ion battery chemistries, making for a potentially viable battery technology out of abundant and cheap materials.
"This is a major development for sodium-ion batteries," said Dr. Imre Gyuk, director of Energy Storage for the Department of Energy's Office of Electricity who supported this work at PNNL. "There is great interest around the potential for replacing Li-ion batteries with Na-ion in many applications."
Lithium-ion batteries are ubiquitous, used in numerous applications such as cell phones, laptops, and electric vehicles. But they are made from materials, such as cobalt and lithium, that are rare, expensive, and found mostly outside the US. As demand for electric vehicles and electricity storage rises, these materials will become harder to get and possibly more expensive. Lithium-based batteries would also be problematic in meeting the tremendous growing demand for power grid energy storage.
On the other hand, sodium-ion batteries, made from cheap, abundant, and sustainable sodium from the earth's oceans or crust, could make a good candidate for large-scale energy storage. Unfortunately, they don't hold as much energy as lithium batteries.
They also have trouble being recharged as would be required for effective energy storage. A key problem for some of the most promising cathode materials is that a layer of inactive sodium crystals builds up at the surface of the cathode, stopping the flow of sodium ions and, consequently, killing the battery.
"The key challenge is for the battery to have both high energy density and a good cycle life," said Junhua Song, lead author on the paper and a WSU PhD graduate who is now at Lawrence Berkeley National Laboratory.
As part of the work, the research team created a layered metal oxide cathode and a liquid electrolyte that included extra sodium ions, creating a saltier soup that had a better interaction with their cathode. Their cathode design and electrolyte system allowed for continued movement of sodium ions, preventing inactive surface crystal build-up and allowing for unimpeded electricity generation.
"Our research revealed the essential correlation between cathode structure evolution and surface interaction with the electrolyte," Lin said. "These are the best results ever reported for a sodium-ion battery with a layered cathode, showing that this is a viable technology that can be comparable to lithium-ion batteries."
The researchers are now working to better understand the important interaction between their electrolyte and the cathode, so they can work with different materials for improved battery design. They also want to design a battery that doesn't use cobalt, another relatively expensive and rare metal.
"This work paves the way toward practical sodium-ion batteries, and the fundamental insights we gained about the cathode-electrolyte interaction shed light on how we might develop future cobalt-free or low cobalt cathode materials in sodium-ion batteries as well as in other types of battery chemistries," Song said. "If we can find viable alternatives to both lithium and cobalt, the sodium-ion battery could truly be competitive with lithium-ion batteries.
"And, that would be a game changer," he added.
Materials provided by Washington State University. Original written by Tina Hilding. Note: Content may be edited for style and length.
